Portable Ultrasonic Watertight Integrity Test Indicator NATO Stock Number 6625-99-257-8336 – UK Government Cage Code KD983 for testing hatches, hatch covers, watertight compartments, storage tanks, bulkheads and doors allows hatch covers to be tested with cargo in situ no messy chalk or water test no time-consuming & expensive vacuum testing unbeatable value versatile unrivalled customer support Portascanner™ ultrasonic hatch cover tester II is an improved version of the Portascanner™, first produced in 1993. The research, development and re-design has been carried out by our in-house team in conjunction with several years’ customer surveys and trials, to improve ultrasonic watertight integrity testing as an alternative to water hose or pressure testing. The new model incorporates lightweight materials and state of the art electronics. The Portascanner™ II both locates a leak site and indicates its extent in a simple hand held format. The unit offers surveyors and inspectors a lightweight, ultrasonic method for inspecting the watertight integrity of ships’ hatch covers, seals, holds, bulk heads and any other holding vessel or water-tight compartment. Being ultrasonic it can be operated even during the loading and unloading of cargo, thereby saving time and costs. The risk of environmental pollution from water run-off and non-compliance with port state rules and regulations are also removed. Classification Society Approval: Ultrasonic watertight integrity testing is approved by members of the International Association of Classification Societies (IACS) and Protection and Indemnity Insurance Clubs (P&I Clubs) Defence Applications: Naval warship and submarine watertight test, watertight seals, armoured vehicle NBC seals, military aircraft airtight seal, tank testing, and naval support vessels. Industrial Applications: Containers, large storage tanks, aircraft airtight integrity, yacht watertight integrity, seaplane floats, soundproof rooms, and holds and hatches. Each Portascanner™ II is supplied as a ready-to-go item in a protective carrying case including: Portascanner™ II receiver headphones standard generator extension rod The Portascanner™ II is a hand-held portable ultrasonic receiver with combined audio and visual signal indication. The Portascanner™ II package comprises of the receiver, carrying case, headphones, generator and extension rod. The receiver converts the ultrasonic signals (40 KHz) from the standard generator into audible signal that can be heard through the headphones and a visual signal can be seen on the LCD screen, a visual indication of the level of ultrasound being detected as a bar graph.The headphones are designed for use in a typically noisy shipboard environment, to cut out most ambient noise. The extension rod enables the operator to use the unit without constantly bending down.

The Portamarine is the world’s leading marine liquid level indicator and has been specially designed to meet the needs commonly experienced when testing on Marine Fire suppression systems. It can be used on FM-200™, NOVEC™ 1230 and a variety of other clean agents but the core design is for working on 45KG / 100Lbs CO2 cylinders in a variety of conditions. The unit uses the proven and very versilite technology from our Portalevel Standard units which has successfully been the core of our raange for nearly 5 years. The range has undergone numerous upgrades to enhance the performance for our customers over this type and a typical cylinder test time is now under 50 seconds. A few core features of this unit includes: The equipment is Classification Society Approved, currently by RINA, and we have units operaing on over 9,000 vessels worldwide. The equipment is proven accurate to +/-1.5mm and has been designed to have handsfree use, allowing the operator to have two free hands to work with during testing. Auto-Calibration facility sets the unit to each cylinder being tested, helping remove user error with manual tuning and increase the speed of testing 2 different power settings, allowing for the unit output to be increased when working on corroded, rusted or poor quality old cylinders. Capability for multi-banked cylinder testing with two rod variants avaliable: Standard Rod – 24mm Standard rod for majority of applications Mini-Rod – 14mm width for tightly packaged cylinder systems Bright LED panel ideal for low light conditions in compartment spaces The primary application for the Portamarine™ is for testing the content of fixed fire suppression cylinders on-board ships and when installed in multi-bank rows 2-3-4 cylinders deep with 20-25mm spacing between each cylinder. This is achieved using ultrasonic technology to send signals into the cylinders. Testing can be achieved without removing the cylinders from their manifold , saving considerable time in testing and reducing risk to the operators. The equipment can work on a wide variety of cylinder types and typical agents include CO2, FM200™, NOVEC 1230™, old Halon Agents, FE-13™, FE-25™, NAF S III™ and all core Clean Agent Systems but it is designed for marine CO2 systems. This equipment will not operate on Inert Gas systems. Portamarine™ is designed for Chief Engineers and Marine Servicing Companies as the ideal tool for use in marine CO2 contents monitoring & servicing requirements. The equipment is very fast to operate, easy to train operators on its use and capable of working on a wide variety of agent & cylinder types without having to change any settings at all. For companies which are still weighing cylinders during servicing, testing is completed with the cylinders remaining in the manifold. This will reduce the time and man-hours required to carry out testing by up to 70% and is much safer with no high pressure cylinders having to be disconnected, moved and reconnected.

The Portalevel® Standard is the core model in the Portalevel® range and ideal for the vast majority of applications. Whilst the core design has been around for nearly 10 years, the unit has gone through substantial upgrades to improve the operation for the operator and update the internal electronics. The unit features the same core features as before including the Auto-CAL and SPA features. The Auto-CAL automatically sets the unit up for each individual cylinder, taking into account all the variables which exist during testing. Having this automatically calibrating to each cylinder removes significant scope for user error and dramatically increases the speed and accuracy with which testing can be achieved. The SPA feature increases the power output of the unit by 25% and increases the sensitivity of receiving the return signal. This allows consistent operation even on challenging applications such as rusted cylinders. The Portalevel® Standard is the most popular and widespread Ultrasonic Level Indicator in the world. We have over 15,000 units operating in 103 countries of the world and this continued success for the unit lies in 3 core areas: SIMPLE: The unit itself is very easy and intuitive to use. The Operating procedure is simple and quick which allows testing to be completed in a short space of time. New users can be trained to reliably operate the equipment with ease. DURABLE: With a proven track record for sustaining rough handling, the Portalevel® Standard will continue operating reliably in harsh conditions for the long term. We pride ourselves on having units operating for 10years+ making our equipment a profitable & reliable investment for our customers. RELIABLE: Proven accurate to +/-1.5mm, achieved Classification Society Approval, CE & EMC tested, customers can be confident in buying a well made product with dependable operation. The Portalevel® Standard is designed for testing the content of fixed fire suppression cylinders. This is achieved using ultrasonic technology to send signals into the cylinders. Testing can be achieved without removing the cylinders from their manifold , saving considerable time in testing and reducing risk to the operators. The equipment can work on a wide variety of cylinder types and typical agents include CO2, FM200™, NOVEC 1230™, old Halon Agents, FE-13™, FE-25™, NAF S III™ and all core Clean Agent Systems. For larger cylinders, please consult the Sales Team for the suitability of the Portalevel® Standard. This equipment will not operate on Inert Gas systems. The Portalevel® Standard is the world’s most popular unit for land based Fire Protection applications, with many thousands of units operating in over 100 countries worldwide. An incredible durable, versatile and dependable unit, the Portalevel® Standard. For companies which are still weighing cylinders during servicing, testing is completed with the cylinders remaining in the manifold. This will reduce the time and man-hours required to carry out testing by up to 70% and is much safer with no high pressure cylinders having to be disconnected, moved and reconnected.

Backround & History We are the OEM of Portalevel™ and Portascanner™ and have been for over 20 years. We have supplied over 15,000 units to customers in 104 countries. These are the basis for becoming the technology manufacturer that we are today manufacturing 14 systems and products. In our niche field of non-invasive, portable and ultrasonic liquid level measurement, we are the world leaders. The business commenced with the development of a portable ultrasonic liquid level indicator for the UK Government Atomic Energy Research Laboratory at Harwell, and was undertaken by Mr Eric Charlton Hunter in 1987, who had previously worked at the Admiralty Research Laboratory and prior to that specialized in Sonar in the Royal Navy Submarine Service. This was called the Portalevel™. The work to establish a portable unit took over 3 years, and was accelerated both by users reluctance to continue to employ radioactive isotope technology because of licensing, transportation and storage restrictions, and by operators who had a personal disinclination to use radioactive technology. Coupled to this, in 1986 the Montreal Protocol was developed to control the use of CFC’s, and in that the company began to receive various UK and USA Government requests to aid their monitoring. Supported by some of the world’s largest fire and marine servicing companies, the 1st production unit was released in 1990.   Company Address: 46 Mount Street, Mayfair, London W1K 2SA, United Kingdom Telephone: +44 2076 298 475 Website: www.coltraco.com
